Maneuverability, reliability in operation (service life up to 15 - 20 years), affordable price - all these are the indisputable advantages of the Micro Rain hose reels offered by the manufacturer -OCMIS (Italy). These multifunctional models are being successfully used to irrigate relatively small plots such as greenhouses, nurseries, small gardens, vineyards, football/golf fields.
Specifications of Hose Reels MICRO RAIN:
|
|
Hose dia. (mm) |
Hose length (m) |
Discharge rate (l/min.) |
Working pressure (atm) |
Irrigation diameter (m) |
|
MR 40 |
40 |
130 |
57/124 |
3,5/7 |
34/46 |
|
MR 43 |
43 |
120 |
57/220 |
3,5/9 |
35/54 |
|
MR 50 |
50 |
170 |
120/290 |
3,5/10 |
36/48 |
|
MR 58 |
58 |
140 |
150/500 |
3/9 |
40/60 |
|
MR 63 |
63 |
110 |
230/600 |
3/8 |
42/68 |
|
MRR 50 |
50 |
230 |
120/290 |
3,5/10 |
36/48 |
|
MRR 58 |
58 |
200 |
150/500 |
3/9 |
40/60 |
|
R1AT15/50 |
50 |
250 |
120/290 |
3,5/10 |
36/48 |
|
R1AT15/58 |
58 |
250 |
150/500 |
3/9 |
40/60 |
|
R1AT15/63 |
63 |
200 |
230/600 |
3/8 |
42/68 |
|
R1AT15/70 |
70 |
150 |
170/600 |
3,5/8 |
25/43 |
OCMIS Hose Reels - a symbol of quality & longevity
OCMIS has been successfully operating in the Italian agricultural machinery market for more than 40 years. To date, the assortment of the plant is represented by a huge number of various sprinkling machines for various tasks. The irrigation equipment of Micro Rain series remains invariably popular throughout the world. There are several reasons for that.
- Long service life;
- No need for complex and expensive maintenance;
- Mobility and ease of operation;
- Possibility to irrigate small areas of any type and shape;
- Any water quality can be used;
- MR series is represented by compact irrigation systems featuring water flow rates 57 - 600 LPM, working pressure 3-10 atm.
Overall dimensions:
|
|
A(sm) |
B(sm) |
C(sm) |
Dry mass (kg) |
Mass with water (kg) |
|
MR 40 |
150 |
126 |
128 |
276 |
384 |
|
MR 43 |
150 |
126 |
128 |
276 |
396 |
|
MR 50 |
190 |
162 |
130 |
403 |
645 |
|
MR 58 |
190 |
162 |
130 |
403 |
682 |
|
MR 63 |
190 |
162 |
130 |
404 |
656 |
|
MRR 50 |
250 |
192 |
130 |
603 |
931 |
|
MRR 58 |
250 |
192 |
130 |
651 |
1050 |
|
R1AT15/50 |
365 |
220 |
166 |
831 |
1187 |
|
R1AT15/58 |
365 |
220 |
166 |
862 |
1361 |
|
R1AT15/63 |
365 |
220 |
166 |
867 |
1325 |
|
R1AT15/70 |
365 |
220 |
166 |
879 |
1297 |
Technical specifications of Sprinklers
Depending on your goals and tasks, you can buy from SMART AGRO company Hose Reels machines of Italian company OCMIS, featuring the following characteristics:
- More than thousand operation hours without repair;
- Hose diameter: 40 - 63 mm;
- Number of sprinkler trolley wheels - 2 pcs;
- Irrigation hose length: 100 - 170 m;
- Exclusive, patented turbine and system guide design for uniform hose winding.
Basic equipment of any machine MR series includes: gearbox, set of nozzles, water gun, connecting pipe (flexible), Glycerin Filled Pressure Gauge, emergency shutdown system.
